Here is an overview of the basic SMT (Surface Mount Technology) assembly line process:1. Incoming Material Inspection

  • Purpose: Ensure the quality of raw materials, including PCB substrates, solder paste, and electronic components.

  • Operation: Use high-precision instruments to check parameters such as dimensions, oxidation levels, and lead flatness. For example, X-ray inspection equipment is used to analyze the solder ball quality of BGA-packaged chips.

2. PCB Loading

  • Purpose: Feed the PCBs into the production line.

  • Operation: An automatic loader neatly places the PCB boards onto the conveyor, ensuring they are flat and undamaged.

3. Solder Paste Printing

  • Purpose: Apply solder paste evenly onto the PCB pads.

  • Operation: A fully automatic solder paste printer transfers solder paste through a stencil onto the pads. The stencil aperture accuracy reaches ±0.01mm, and solder paste thickness is monitored in real time by laser sensors.

    4. Pick & Place

    • Purpose: Accurately place electronic components on the designated positions of the PCB.

    • Operation: A high-speed pick-and-place machine places tiny components at rates of tens of thousands per minute, with placement accuracy up to ±25μm.

    5. Reflow Soldering

    • Purpose: Heat the solder paste to melt it and form reliable solder joints between components and the PCB.

    • Operation: The assembled PCBs pass through a reflow oven with four temperature zones: preheat, soak, reflow, and cooling. The temperature profile must be precisely controlled—for example, lead-free processes typically peak at ~245°C, with a duration under 10 seconds.

    6. AOI Inspection

    • Purpose: Detect defects after soldering.

    • Operation: An Automatic Optical Inspection (AOI) machine scans the soldered boards to identify issues such as tombstoning, misalignment, or cold joints.

    7. Rework/Repair

    • Purpose: Fix soldering defects or quality issues found during inspection.

    • Operation: Rework stations repair defective boards to ensure final product quality.

  • 8. Cleaning

    • Purpose: Remove soldering residues and contaminants from the PCB.

    • Operation: A cleaning machine with appropriate cleaning solutions and processes is used to avoid damaging the product.

    9. Functional Testing

    • Purpose: Verify that the product functions and performs as required.

    • Operation: Functional testers and other instruments ensure the PCBs meet design specifications.

    10. Packaging

    • Purpose: Protect the products and facilitate usage.

    • Operation: Qualified PCBs are packed in reels, trays, tubes, or bags according to customer requirements.

    11. PCB Unloading

    • Purpose: Collect finished PCBs from the production line.

    • Operation: An automatic unloader neatly transfers the boards into boxes for further packaging and shipment.
